NBB20-L2-E2-V1 Pepperl Fuchs Inductive Sensor
NBB20-L2-E2-V1 Pepperl Fuchs Inductive Sensor
NBB20-L2-E2-V1 Pepperl Fuchs...
NBB20-L2-E2-V1 Pepperl Fuchs...

NBB20-L2-E2-V1 Pepperl Fuchs Inductive Sensor

Pepperl Fuchs NBB20-L2-E2-V1 Inductive Sensor Part: 187481, 10-30V, 20mm Range, PNP NO

₱ 2,800.00
Tax excluded

Description

Pepperl Fuchs NBB20-L2-E2-V1 Inductive Sensor Part: 187481.

General Parameters :

Switching element function : PNP NO

Setup : flush

Working Distance : 20mm

Output DC

Assured operating distance sa 0 ... 16.2 mm

Reduction factor rAl 0.33

Reduction factor rCu 0.31

Reduction factor r304 0.74

Reduction factor rBrass 0.41

Nominal ratings

Voltage UB 10 ... 30 V

Frequency Range f 0 ... 150 Hz

Hysteresis H typ. 5 %

Reverse polarity protection reverse polarity protected

Short-circuit protection pulsing

Voltage drop Ud ≤ 2 V

Operating current IL 0 ... 200 mA

Off-state current Ir 0 ... 0.5 mA typ. 0.1 µA at 25 °C

No-load supply current I0 ≤ 20 mA

Time delay before availability tv 80 ms

Operating voltage indicator LED, green

Switching state indicator LED, yellow

Ambient conditions

Ambient temperature -25 ... 85 °C (-13 ... 185 °F)

Storage temperature -40 ... 85 °C (-40 ... 185 °F)

Mechanical specifications

Connection type Connector M12 x 1 , 4-pin

Housing material PA

Sensing face PA

Degree of protection IP69K

Weight 130 g

Disclaimer : Jhing Industrial Supply is not an authorized distributor, dealer, agent or associate of the manufacturer mentioned here. All product names, trademarks, brands and logos used on this site are the property of their respective owners.

Product Details

NBB20-L2-E2-V1
